Raption
37Instruction Manual
H
Connectors status
The HMI screen shows a different symbols over the connector pictures, as you can see below:
It means that there is not any problem in this connector and is ready
for use.
This connector is out of service for any technical reason. Press over
‘Information’ touch button in order to get more information about it.
The Charge Point is out of service because the emergency button has
been pressed. This fact affects all the connectors at the same time.
The connector is disabled. The Charge Point is out of order due to some
maintenance job or because the Back office has decided to stop it.
