Circutor RGU-10 - SETTING BY SETUP

31
Instruction Manual
RGU-10, RGU-10C
5.2.- SETTING BY SETUP
“PROG”andtherstmenuoptionappearonthedisplaybypressingalongtimethePROG/
PAG key. Once in menu setting mode, the different text indicators appear on the display after
each time PROG is pressed.
When the correct menu is reached, the parameter can be changed by pressing td (rotating).
In order to enter the settings press the PROG but on again with the “SAVE” message showing
the version of the device. The display the turns to the initial screen.
If, after a certain time, the keyboard remains inactive the “EXIt” message appears and the main
relay settings are shown without any information being saved.
A�- RGU-10C congurationmenu
PROG
td
PROG
PROG
td
td
td
PROG
td
PROG
td
td
PROG
Figure 30: RGU-10C conguration menu.
