Cisco 350 Series Administration Guide

Administration
Plug-n-Play (PNP)
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 87
6
PNP Session
This screen displays the value of the PNP parameters currently in effect. The source of the
parameter is displayed in parenthesis where relevant.
To display information about PNP parameters:
STEP 1 Click Administration > PNP > PNP Session.
The following fields are displayed:
• Administrative Status—Whether PNP is enabled or not.
• Operational Status—Is PNP operational.
• PNP Agent State—Indicates whether there is an active PNP session. The possible
values are Discovery Wait; Discovery; Not Ready; Disabled; Session; Session Wait.
• Transport Protocol– Displays the PNP agent session information.
• TCP Port—TCP port of the PNP session
• Server IP Address—IP address of PNP server
• Username—Username to be sent in PNP packets
• Password MD5—Password to be sent in PNP packets
• Discovery Timeout—Discovery timeout configured
• Session Interval Timeout—Session Interval timeout configured (appears only when
PNP Agent State is Waiting)
• Remaining Timeout—Value of remaining timeout.
NOTE Click the Resume button to immediately take the PnP agent out of the waiting state, in the
following way:
• If the agent is in the Discovery Waiting state, it is set to the Discovery state.
• If the agent is in the PnP Session Waiting state, it is set to the PnP Session state.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
