Cisco 350 Series Administration Guide

Access Control
IPv6-Based ACL Creation
406 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
22
- IGMP Type to match—Number of message type that is to be used for filtering
purposes.
STEP 5 Click Apply. The IPv4-based ACE is saved to the Running Configuration file.
IPv6-Based ACL Creation
The IPv6-Based ACL page displays and enables the creation of IPv6 ACLs, which check pure
IPv6-based traffic. IPv6 ACLs do not check IPv6-over-IPv4 or ARP packets.
NOTE ACLs are also used as the building elements of flow definitions for per-flow QoS handling.
IPv6-Based ACL
To define an IPv6-based ACL:
STEP 1 Click Access Control > IPv6-Based ACL.
This window contains the list of defined ACLs and their contents
STEP 2 Click Add.
STEP 3 Enter the name of a new ACL in the ACL Name field. The names are case-sensitive.
STEP 4 Click Apply. The IPv6-based ACL is saved to the Running Configuration file.
IPv6-Based ACE
NOTE Each IPv6-based rule consumes two TCAM rules.
STEP 1 Click Access Control > IPv6-Based ACE.
This window contains the ACE (rules) for a specified ACL (group of rules).
STEP 2 Select an ACL, and click Go. All currently-defined IP ACEs for the selected ACL are
displayed.
STEP 3 Click Add.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
