Administration: File Management
File Operations
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 101
7
STEP 5 Select one of the following methods to perform SSH Client Authentication:
• Use SSH Client System Credentials—Sets permanent SSH user credentials. Click
System Credentials to go to the SSH User Authentication page where the user/
password can be set once for all future use.
• Use SSH Client One-Time Credentials—Enter the following:
- Username—Enter a username for this copy action.
- Password—Enter a password for this copy.
NOTE The username and password for one-time credential will not saved in
configuration file.
• Server Definition—Select whether to specify the SCP server by IP address or by
domain name.
If Server Definition is By Address:
- IP Version—Select whether an IPv4 or an IPv6 address is used.
- IPv6 Address Type—Select the IPv6 address type (if used). The options are:
Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication only on the local network. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
- Link Local Interface—Select the link local interface from the list.
• Server IP Address/Name—Enter the IP address or name of the SCP server.
• Source—Enter the name of the source file.
STEP 6 Click Apply to begin the operation.
To backup a system configuration file using HTTP/HTTPS:
STEP 1 Click Administration > File Management > File Operations.
STEP 2 Enter the following fields:
• Operation Type—Select Backup File.
