Administration: File Management
File Operations
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 103
7
To backup a system configuration file using TFTP:
STEP 1 Click Administration > File Management > File Operations.
STEP 2 Enter the following fields:
• Operation Type—Select Backup File.
• Source File Type—Select the type of file to be backed up.
• Copy Method—Select TFTP.
• Server Definition—Select whether to specify the TFTP server by IP address or by
domain name.
If Server Definition is By Address:
- IP Version—Select whether an IPv4 or an IPv6 address is used.
If the server is selected by name in the Server Definition, there is no need to select
the IP Version related options.
- IPv6 Address Type—Select the IPv6 address type (if used). The options are:
Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication only on the local network. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
- Link Local Interface—Select the link local interface from the list.
• Server IP Address/Name—Enter the IP address or name of the TFTP server.
• Destination—Enter the backup file name.
• Sensitive Data Handling—Select how sensitive data should be included in the backup
file. The following options are available:
- Exclude—Do not include sensitive data in the backup.
- Encrypt—Include sensitive data in the backup in its encrypted form.
- Plaintext—Include sensitive data in the backup in its plaintext form.
NOTE The available sensitive data options are determined by the current user SSD
rules. For details, refer to Secure Sensitive Data Management > SSD Rules page.
