Cisco 350 Series Administration Guide

Administration: Stack Management
Software Auto Synchronization in Stack
131 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
8
The feature set of the Sx350X and SG350XG/SX350X is the same, and similarly the feature
set of the Sx550X and SG550XG/SX550X is the same. However there are a few differences in
feature support and table sizes. For these features, hybrid stack supports the lowest
denominator for these features/tables. The following is list of differences per each hybrid stack
type, and the setting used in each unit type and in the hybrid stack:
Feature/Table Sx550X SG550XG/
SX550X
Hybrid Stack
OOB port Not Supported Supported Not Supported
MAC table size 16K 32K 16K
ACL TCAM 3K- reserved 2K- reserved 2K- reserved
ARP table size 4K – reserved 8K – reserved 4K – reserved
Max MAC table aging 400 630 400
Feature/Table Sx350X SG350XG/
SX350X
Hybrid Stack
OOB port Not Supported Supported Not Supported
MAC table size 16K 32K 16K
ACL TCAM 1K- reserved 2K- reserved 1K- reserved
Router TCAM 992 7168 (affects
also default
and Max
setting per
each type)
992
ARP table size 1K – reserved 8K – reserved 1K – reserved
Number of Multicast groups 2K 4K 2K
Max. number of IPv4 routes 990 7168 990
Max. number of IPv4 host
directly-connected
820 7092 820
Max. number of IPv4
Multicast routes
255 1800 255
Max number of IPv6
interfaces
106 200 106

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
