VLAN Management
226 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
12
The following describes server/router traffic (reply to host).
Figure 2 Server/Router Traffic to Hosts
Isolated 1 Isolated 2
Server
Community 1 Community 1
Promiscous Promiscous
Isolated Isolated Community Community Community
Community 1
Primary VLAN
