Cisco 350 Series Administration Guide

VLAN Management
VLAN Groups
244 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
12
MAC-Based Groups
See Table 1 for a description of the availability of this feature.
To assign a MAC address to a VLAN Group:
STEP 1 Click VLAN Management > VLAN Groups > MAC-Based Groups.
STEP 2 Click Add.
STEP 3 Enter the values for the following fields:
• MAC Address—Enter a MAC address to be assigned to a VLAN group.
NOTE This MAC address cannot be assigned to any other VLAN group.
• Prefix Mask—Enter one of the following:
- Host(48)—To include all bits of MAC address in the prefix mask (48 bits)
- Length—Prefix of the MAC address
• Group ID—Enter a user-created VLAN group ID number.
STEP 4 Click Apply. The MAC address is assigned to a VLAN group.
MAC-Based Groups to VLAN
See Table 1 for a description of the availability of this feature.
Ports/LAGs must be in General mode.
To assign a MAC-based VLAN group to a VLAN on an interface:
STEP 1 Click VLAN Management > VLAN Groups > MAC-Based Groups to VLAN.
STEP 2 Click Add.
STEP 3 Enter the values for the following fields:
• Group Type—Displays that the group is MAC-Based.
• Interface—Enter a general interface (port/LAG) through which traffic is received.
• Group ID—Select a VLAN group, defined in the MAC-Based VLAN Group Overview
page.
• VLAN ID—Select the VLAN to which traffic from the VLAN group is forwarded.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
