Cisco 350 Series Administration Guide

VLAN Management
VLAN Groups
246 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
12
STEP 4 Click Apply. The group is added, and written to the Running Configuration file.
Subnet-Based Groups to VLAN
To map a subnet group to a port, the port must not have DVA configured on it (see Interface
Settings).
Several groups can be bound to a single port, with each port being associated to its own
VLAN.
It is possible to map several groups to a single VLAN as well.
To map the subnet group to a VLAN:
STEP 1 Click VLAN Management > VLAN Groups > Subnet-Based Groups to VLAN.
The currently-defined mappings are displayed.
STEP 2 To associate an interface with a protocol-based group and VLAN, click Add.
The Group Type field displays the type of group being mapped.
STEP 3 Enter the following fields.
• Interface—Port or LAG number assigned to VLAN according to protocol-based group.
• Group ID—Protocol group ID.
• VLAN ID—Attaches the specified group for this interface to a user-defined VLAN ID.
STEP 4 Click Apply. The subnet-based group ports are mapped to VLANs, and written to the Running
Configuration file.
Protocol-Based VLAN Groups Overview
Groups of protocols can be defined and then bound to a port. After the protocol group is bound
to a port, every packet originating from a protocol in the group is assigned the VLAN that is
configured in the Protocol-Based Groups page.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
