VLAN Management
Voice VLAN
258 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
12
The Voice VLAN Local Source Table displays voice VLAN configured on the device, as
well as any voice VLAN configuration advertised by directly-connected neighbor devices. It
contains the following fields:
• Interface—Displays the interface on which voice VLAN configuration was received or
configured. If N/A appears, the configuration was done on the device itself. If an
interface appears, a voice configuration was received from a neighbor.
• Source MAC Address— MAC address of a UC from which the voice configuration
was received.
• Source Type— Type of UC from which voice configuration was received. The
following options are available:
- Default—Default voice VLAN configuration on the device
- Static—User-defined voice VLAN configuration defined on the device.
- CDP—UC that advertised voice VLAN configuration is running CDP.
- LLDP—UC that advertised voice VLAN configuration is running LLDP.
- Voice VLAN ID—The identifier of the advertised or configured voice VLAN
• Voice VLAN ID—The identifier of the current voice VLAN.
• CoS/802.1p—The advertised or configured CoS/802.1p values that are used by the
LLDP-MED as a voice network policy.
• DSCP—The advertised or configured DSCP values that are used by the LLDP-MED as
a voice network policy.
• Best Local Source—Displays whether this voice VLAN was used by the device. The
following options are available:
- Yes—The device uses this voice VLAN to synchronize with other Auto Voice
VLAN-enabled switches. This voice VLAN is the voice VLAN for the network
unless a voice VLAN from a higher priority source is discovered. Only one local
source is the best local source.
- No—This is not the best local source.
STEP 3 Click Refresh to refresh the information on the page
