Cisco 350 Series Administration Guide

IP Configuration
IPv4 Management and Interfaces
288 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
16
IPv4 Forwarding Table
To view the IPv4 Forwarding Table:
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > IPv4 Forwarding Table.
The IPv4 Forwarding Table is displayed. The following fields are displayed for each entry:
• Destination IP Prefix—Destination IP address prefix.
• Prefix Length— IP route prefix for the length of the destination IP.
• Route Type—Whether the route is a local, reject or remote route.
• Next Hop Router IP Address—The next hop IP address.
• Route Owner—This can be one of the following options:
- Default—Route was configured by default system configuration.
- Static—Route was manually created.
- Dynamic—Route was created by an IP routing protocol.
- DHCP—Route was received from a DHCP server.
- Directly Connected—Route is a subnet to which the device is connected.
• Metric—Cost of this hop (a lower value is preferred).
• Administrative Distance—The administrative distance to the next hop (a lower value
is preferred). This is not relevant for static routes.
• Outgoing Interface—Outgoing interface for this route.
RIPv2
See IP Configuration: RIPv2.
VRRP
See IP Configuration: VRRP

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
