Cisco 350 Series Administration Guide

IP Configuration
IPv6 Management and Interfaces
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 331
16
- Description—Text.
• IPv6 Prefix—IP route prefix.
• Prefix Length—IP route prefix length.
• Greater Than—Minimum prefix length to be used for matching. Select one of the
following options:
- No Limit—No minimum prefix length to be used for matching.
- User Defined—Minimum prefix length to be matched.
• Lower Than—Maximum prefix length to be used for matching. Select one of the
following options:
- No Limit—No maximum prefix length to be used for matching.
- User Defined—Maximum prefix length to be matched.
• Description—Enter a description of the prefix list.
STEP 4 Click Apply to save the configuration to the Running Configuration file.
IPv6 Access Lists
The IPv6 access list can be used in MLD Proxy > Global MLD Proxy Settings > SSM IPv6
Access List page.
To create an access list:
STEP 1 Click IP Configuration > IPv6 Management and Interfaces > IPv6 Access List.
STEP 2 To add a new Access List, click Add and enter the following fields:
• Access List Name—Select one of the following:
- Use Existing List—Select a previously-existing access list.
- Create new list—Enter a name for the new access list.
• Source IPv6 Address—Enter the source IPv6 address. The following options are
available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
