Cisco 350 Series Administration Guide

IP Configuration: RIPv2
Configuring RIP
341 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
18
To enable/disable RIP on the device.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces> RIPv2 > RIPv2 Properties.
STEP 2 Select the following options as required:
• RIP—The following options are available:
- Enable—Enable RIP.
- Disable—Disable RIP. Disabling RIP deletes the RIP configuration on the system.
- Shutdown—Set the RIP global state to shutdown.
• RIP Advertisement—Select to enable sending routing updates on all RIP IP interfaces.
• Default Route Advertisement—Select to enable sending the default route to the RIP
domain. This route will serve as the default router.
• Default Metric—Enter the value of the default metric (refer to Redistribution Feature).
STEP 3 Redistribute Static Route—Select to enable this feature (described in Redistribution Feature.
STEP 4 If Redistribute Static Route is enabled, select an option for the Redistribute Static Metric
field. The following options are available:
• Default Metric—Causes RIP to use the default metric value for the propagated static
route configuration (refer to Redistribution Feature).
• Transparent—Causes RIP to use the routing table metric as the RIP metric for the
propagated static route configuration. This results in the following behavior:
- If the metric value of a static route is equal to or less than 15, this value is used in
the RIP protocol when advertising this static route.
- If the metric value of a static route is greater than 15, the static route is not advertised
to other routers using RIP.
• User Defined Metric—Enter the value of the metric.
STEP 5 Redistribute Connected Route—Select to enable this feature (described in Redistributing
Static Route Configuration.
STEP 6 If Redistribute Connected Route is enabled, select an option for the Redistribute
Connected Metric field. The following options are available:
• Default Metric—Causes RIP to use the default metric value for the propagated static
route configuration (refer to Redistribution Feature).

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
