Cisco 350 Series Administration Guide

Security: 802.1X Authentication
Supplicant Credentials
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 375
18
To preview the login or success message, click Preview.
To set the default language of the GUI interface as the default language for Web-based
authentication, click Set Default Display Language.
Supplicant Credentials
This page enables creating and configuring credentials that can be used by an interface
configured as an 802.1x supplicant.
To add a supplicant’s credentials:
STEP 1 Click Security > 802.1X Authentication > Supplicant Credentials.
STEP 2 Click Add.
STEP 3 Enter the following fields:
• Credential Name—Name by which to identify the credential.
• User Name—Enter the user name associated with the credential name.
• Description—Enter text describing the user.
• Password—Select the type of password: Encrypted or Plaintext and add the
password.
STEP 4 Click Apply and the settings are saved to the Running Configuration file.
MAC-Based Authentication Settings
This page enables you to configure various setting to apply to MAC-based authentication.
To configure MAC-based authentication:
STEP 1 Click Security > 802.1X Authentication > MAC-Based Authentication Settings
STEP 2 Enter the following fields:
• MAC Authentication Type—Select one of the following options:

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
