Cisco 350 Series Administration Guide

Quality of Service
General
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 423
23
To map DSCP to queues:
STEP 1 Click Quality of Service > General > DSCP to Queue.
The DSCP to Queue page contains Ingress DSCP. It displays the DSCP value in the incoming
packet and its associated class.
STEP 2 Select the Output Queue (traffic forwarding queue) to which the DSCP value is mapped.
STEP 3 Click Apply. The Running Configuration file is updated.
Queue
7 78 65431
DSCP
60 52 44 36 28 20 12 4
Queue
7 78 65431
DSCP
59 51 43 35 27 19 11 3
Queue
7 78 65431
DSCP
58 50 42 34 26 18 10 2
Queue
7 78 65431
DSCP
57 49 41 33 25 17 9 1
Queue
7 78 65431
DSCP
56 48 40 32 24 16 8 0
Queue
7 77 87712

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
