Cisco 350 Series Administration Guide

Quality of Service
QoS Advanced Mode
438 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
23
• An action to be applied to frames that are over the limits (called out-of-profile traffic),
where such frames can be passed as is, dropped, or passed, but remapped to a new
DSCP value that marks them as lower-priority frames for all subsequent handling
within the device.
• Configures traffic policing on the basis of the specified rates and optional actions.
Enter the CIR and these optional values and actions.
Assigning a policer to a class map is done when a class map is added to a policy. If the policer
is an aggregate policer, you must create it using the Aggregate Policer page.
To define an aggregate policer:
STEP 1 Click Quality of Service > QoS Advanced Mode > Aggregate Policer.
This page displays the existing aggregate policers.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• Aggregate Policer Name—Enter the name of the Aggregate Policer.
• Ingress Committed Information Rate (CIR)—Enter the maximum bandwidth
allowed in bits per second. See the description of this in the Bandwidth page.
• Ingress Committed Burst Size (CBS)—Enter the maximum burst size (even if it goes
beyond the CIR) in bytes. See the description of this in the Bandwidth page.
• Exceed Action—Select the action to be performed on incoming packets that exceed the
CIR. Possible values are:
- Drop—Packets exceeding the defined CIR value are dropped.
- Out of Profile DSCP—The DSCP values of packets exceeding the defined CIR
value are remapped to a value based on the Out Of Profile DSCP Remarking Table.
• Peak Enforcement—Select to enable action if peak burst size is exceeded.
• Peak Information Rate (PIR)—Enter the peak traffic rate (PIR) in kbits per second
(kbps).
• Peak Burst Size (PBS)—Enter the peak burst size (PIR) in kbits per second (kbps).
• Violate Action—Select one of the following actions if peak size is exceeded:.
- Drop—Drop the frames violating the peak size.
- Out-of-Profile DSCP—Mark frames violating the peak size with the DSCP value
with previously-set DSCP value.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
