Quality of Service
QoS Advanced Mode
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 441
23
flow traffic will be mirrored but not forwarded to the egress network interface
(drop behavior).
- Traffic flows on interfaces, to which policy is applied that do not match the
Mirrored class map classification, will follow the default policy default action.
• Police Type—Select the policer type for the policy. The options are:
- None—No policy is used.
- Single—The policer for the policy is a single policer.
- Aggregate—The policer for the policy is an aggregate policer.
STEP 5 If Police Type is Aggregate, select the Aggregate Policer.
STEP 6 If Police Type is Single, enter the following QoS parameters:
• Ingress Committed Information Rate (CIR)—Enter the CIR in Kbps. See a
description of this in the Bandwidth page.
• Ingress Committed Burst Size (CBS)—Enter the CBS in bytes. See a description of
this in the Bandwidth page.
• Exceed Action—Select the action assigned to incoming packets exceeding the CIR.
The options are:
- Drop—Packets exceeding the defined CIR value are dropped.
- Out of Profile DSCP—IP packets exceeding the defined CIR are forwarding with a
new DSCP derived from the Out Of Profile DSCP Remarking Table.
• Peak Enforcement—Select to enable action if peak burst size is exceeded.
• Peak Information Rate (PIR)—Enter the peak traffic rate (PIR) in kbits per second
(kbps).
• Peak Burst Size (PBS)—Enter the peak burst size (PIR) in kbits per second (kbps).
• Violate Action—Select one of the following actions if peak size is exceeded:.
- Drop—Drop the frames violating the peak size.
- Out-of-Profile DSCP—Mark frames violating the peak size with the DSCP value
with previously-set DSCP value.
STEP 7 Click Apply.
