Smart Network Application (SNA)
Right-Hand Information Panel
488 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
25
Notifications Block
The notification block displays the latest notifications (SYSLOGs) recorded on the selected
device.
The notifications section only appears when selecting a single SNA device.
See Notifications for additional details.
Services Block
This section of the information panel displays available services for the current selection of
elements. Only services that are relevant for all selected elements are displayed. This section is
not displayed if elements, which do not support services, are a part of the selection, or when
devices and interfaces are selected together.
See Services for additional information.
Tags
Tags are used to identify elements in the topology by attributes (see Tags). The Tag block of
the right-hand information displays all the tags assigned to the element, either automatically or
by the user. You can also manage the tags of the selected elements from this part of the panel.
See Tags for additional information.
Statistics
When viewing an SNA-capable device, or the interfaces on an SNA-capable device, you can
select to view historical statistics information on that interface or device.
The Statistics view is accessed from the right-hand information panel.
To view historical statistics on an interface or device, select a specific parameter to view from
a list of available parameters, according to the parameters supported by the embedded counters
history feature. You can then view the status of this parameter on the selected interface for the
previous year.
