Status and Statistics
Switched Port Analyzer (SPAN and RSPAN)
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 67
5
STEP 3 Click Apply.
SPAN Session Destinations
A destination port must be configured on the start and final devices. On the start device, this is
the reflector port. On the final device, it is the analyzer port.
To add a destination port:
STEP 1 Click Status and Statistics > SPAN & RSPAN > Session Destinations.
The previously-defined destinations are displayed.
STEP 2 Click Add.
STEP 3 Enter the following fields:
• Session ID—Select a session ID. This must match the session IDs of the source ports.
• Destination Type—Select one of the following options:
- Local Interface—Is the destination port on the same device as the source ports
(relevant to SPAN).
- Remote VLAN—Is the destination port on a different device than the source port
(relevant to RSPAN).
If the Destination Type is Remote VLAN, configure the following field:
- Reflector Port—Select a unit/port that functions as a target port on the first device.
If the Destination Type is Local Interface, configure the following field:
- Port—Select a unit/port that functions as the analyzer port on the device.
• Network Traffic—Select to enable that traffic other than monitored traffic is possible
on the port.
STEP 4 Click Apply.
SPAN Session Sources
One or more SPAN or RSPAN sources must be configured on the start and final devices.
