Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Security Features
Configuring VPN
Step 3
dns primary-server
Example:
Router(config-isakmp-group)# dns 10.50.10.1
Router(config-isakmp-group)#
Specifies the primary DNS
1
server for the group.
You may also want to specify WINS
2
servers for
the group by using the wins command.
Step 4
domain name
Example:
Router(config-isakmp-group)# domain
company.com
Router(config-isakmp-group)#
Specifies group domain membership.
Step 5
exit
Example:
Router(config-isakmp-group)# exit
Router(config)#
Exits IKE group policy configuration mode and
enters global configuration mode.
Step 6
ip local pool {default | poolname}
[low-ip-address [high-ip-address]]
Example:
Router(config)# ip local pool dynpool
30.30.30.20 30.30.30.30
Router(config)#
Specifies a local address pool for the group.
For details about this command and additional
parameters that can be set, see Cisco IOS Dial
Technologies Command Reference.
1. DNS = Domain Name System
2. WINS = Windows Internet Naming Service
Command or Action Purpose

Cisco 3925 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity Technology	Wired
Power	AC 120/230 V (50/60 Hz)
Redundant Power Supply	Optional
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, PIM
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP
Encryption Algorithm	DES, Triple DES, AES
Flash Memory	256 MB
Weight	11.5 kg
Interfaces	2 x SFP (mini-GBIC)
Power Source	Internal power supply
Authentication Method	RADIUS, TACACS+, LDAP
Compliant Standards	IEEE 802.1Q, IEEE 802.3af
Operating Temperature	0 to 40 °C
Operating Humidity	5% to 85% (non-condensing)
Dimensions (WxDxH)	44.5 x 47.2 x 8.9 cm
