Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
Provisioning Service (CE-A)
Perform this task to set up service for Ethernet CFM. Optionally, when this task is completed, you may
configure and enable the cross-check function. To perform this optional task, see "Configuring and
Enabling the Cross-Check Function (CE-A)".
SUMMARY STEPS
Step 1 enable
Step 2 configure terminal
Step 3 ethernet cfm domain domain-name level level-id
Step 4 service {ma-name | ma-num | vlan-id vlan-id | vpn-id vpn-id} [port | vlan vlan-id [direction down]]
Step 5 continuity-check [interval time | loss-threshold threshold | static rmep]
Step 6 continuity-check [interval time | loss-threshold threshold | static rmep]
Step 7 continuity-check [interval time | loss-threshold threshold | static rmep]
Step 8 exit
Step 9 mep archive-hold-time minutes
Step 10 exit
Step 11 ethernet cfm global
Step 12 ethernet cfm ieee
Step 13 ethernet cfm traceroute cache
Step 14 ethernet cfm traceroute cache size entries
Step 15 ethernet cfm traceroute cache hold-time minutes
Step 16 interface type number
Step 17 ethernet cfm mep domain domain-name mpid mpid {port | vlan vlan-id}
Step 18 ethernet cfm mep domain domain-name mpid mpid {port | vlan vlan-id}
Step 19 end
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router> enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.

Cisco 3925 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity Technology	Wired
Power	AC 120/230 V (50/60 Hz)
Redundant Power Supply	Optional
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, PIM
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP
Encryption Algorithm	DES, Triple DES, AES
Flash Memory	256 MB
Weight	11.5 kg
Interfaces	2 x SFP (mini-GBIC)
Power Source	Internal power supply
Authentication Method	RADIUS, TACACS+, LDAP
Compliant Standards	IEEE 802.1Q, IEEE 802.3af
Operating Temperature	0 to 40 °C
Operating Humidity	5% to 85% (non-condensing)
Dimensions (WxDxH)	44.5 x 47.2 x 8.9 cm
