Cisco 3925 User Manual

147
Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Security Features
Configuring VPN
Step 3
tunnel source interface-type number
Example:
Router(config-if)# tunnel source
fastethernet 0
Router(config-if)#
Specifies the source endpoint of the router for the
GRE tunnel.
Step 4
tunnel destination default-gateway-ip-address
Example:
Router(config-if)# tunnel destination
192.168.101.1
Router(config-if)#
Specifies the destination endpoint of the router for
the GRE tunnel.
Step 5
crypto map map-name
Example:
Router(config-if)# crypto map static-map
Router(config-if)#
Assigns a crypto map to the tunnel.
Note Dynamic routing or static routes to the
tunnel interface must be configured to
establish connectivity between the sites.
See Cisco IOS Security Configuration
Guide: Secure Connectivity, Release
12.4T for details.
Step 6
exit
Example:
Router(config-if)# exit
Router(config)#
Exits interface configuration mode and returns to
global configuration mode.
Step 7
ip access-list {standard | extended}
access-list-name
Example:
Router(config)# ip access-list extended
vpnstatic1
Router(config-acl)#
Enters ACL
1
configuration mode for the named
ACL that the crypto map uses.
Step 8
permit protocol source source-wildcard
destination destination-wildcard
Example:
Router(config-acl)# permit gre host
192.168.100.1 host 192.168.101.1
Router(config-acl)#
Specifies that only GRE traffic is permitted on the
outbound interface.
Step 9
exit
Example:
Router(config-acl)# exit
Router(config)#
Returns to global configuration mode.
1. ACL = access control list
Command or Action Purpose

Cisco 3925 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity Technology	Wired
Power	AC 120/230 V (50/60 Hz)
Redundant Power Supply	Optional
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, PIM
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP
Encryption Algorithm	DES, Triple DES, AES
Flash Memory	256 MB
Weight	11.5 kg
Interfaces	2 x SFP (mini-GBIC)
Power Source	Internal power supply
Authentication Method	RADIUS, TACACS+, LDAP
Compliant Standards	IEEE 802.1Q, IEEE 802.3af
Operating Temperature	0 to 40 °C
Operating Humidity	5% to 85% (non-condensing)
Dimensions (WxDxH)	44.5 x 47.2 x 8.9 cm
