Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
Configuring a Network Interface Device on the L3 Interface
Step 2 configure terminal
Step 3 interface gigabitethernet slot/port
Step 4 port-tagging
Step 5 encapsulation dot1q vlan-id
Step 6 set cos cos-value
Step 7 end
DETAILED STEPS
Configuration Example
This configuration example shows how to configure the NID:
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router#configure terminal
Enters the global configuration mode.
Step 3
interface gigabitethernet slot/port
Example:
Router(config)#interface
gigabitethernet 0/2
Specifies an interface and enters the interface
configuration mode.
Step 4
port-tagging
Example:
Router(config-if)#port-tagging
Inserts the VLAN ID into a packet header to identify
which Virtual Local Area Network (VLAN) the packet
belongs to.
Step 5
encapsulation dot1q vlan-id
Example:
Router(config-if-port-tagging)#encaps
ulation dot1q 10
Defines the encapsulation format as IEEE 802.1Q
(dot1q), and specifies the VLAN identifier.
Step 6
set cos cos-value
Example:
Router(config-if-port-tagging)#set
cos 6
Sets the Layer 2 class of service (CoS) value to an
outgoing packet end.
Step 7
end
Example:
Router(config-if-port-tagging)#end
Exits the interface configuration mode.

Cisco 3925 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity Technology	Wired
Power	AC 120/230 V (50/60 Hz)
Redundant Power Supply	Optional
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, PIM
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP
Encryption Algorithm	DES, Triple DES, AES
Flash Memory	256 MB
Weight	11.5 kg
Interfaces	2 x SFP (mini-GBIC)
Power Source	Internal power supply
Authentication Method	RADIUS, TACACS+, LDAP
Compliant Standards	IEEE 802.1Q, IEEE 802.3af
Operating Temperature	0 to 40 °C
Operating Humidity	5% to 85% (non-condensing)
Dimensions (WxDxH)	44.5 x 47.2 x 8.9 cm
