Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
CFM Support on Routed Port and Port MEP
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router#configure terminal
Enters the global configuration mode.
Step 3
ethernet cfm ieee
Example:
Router(config)#ethernet cfm ieee
Enables the IEEE version of CFM.
Step 4
ethernet cfm global
Example:
Router(config)#ethernet cfm global
Enables CFM processing globally on the router.
Step 5
ethernet cfm domain domain-name level
0 to 7
Example:
Router(config-ecfm)#ethernet cfm
domain customer level 7
Defines a CFM maintenance domain at a specified level,
and enters Ethernet CFM configuration mode.
level can be any value from 0 to 7.
Step 6
service service-name vlan vlan-id
inner-vlan inner vlan-id direction
down
Example:
Router(config-ecfm)#service
customer1101 vlan 100 inner-vlan 30
direction down
Enters the CFM service configuration mode.
The following are the parameters:
• vlan—Specifies the VLAN.
• inner-vlan—The inner-vlan keyword and the inner
vlan-id argument specify the VLAN tag for
double-tagged packets.
Step 7
continuity-check
Example:
Router(config-ecfm-srv)#continuity-ch
eck
Enables sending continuity check messages.
Step 8
interface gigabitethernet slot/port
Example:
Router(config-ecfm-srv)#interface
gigabitethernet 0/2
Specifies an interface and enters the interface
configuration mode.

Cisco 3925 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity Technology	Wired
Power	AC 120/230 V (50/60 Hz)
Redundant Power Supply	Optional
Routing Protocol	OSPF, IS-IS, BGP, EIGRP, PIM
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP
Encryption Algorithm	DES, Triple DES, AES
Flash Memory	256 MB
Weight	11.5 kg
Interfaces	2 x SFP (mini-GBIC)
Power Source	Internal power supply
Authentication Method	RADIUS, TACACS+, LDAP
Compliant Standards	IEEE 802.1Q, IEEE 802.3af
Operating Temperature	0 to 40 °C
Operating Humidity	5% to 85% (non-condensing)
Dimensions (WxDxH)	44.5 x 47.2 x 8.9 cm
