If you remove the system power cords before the graceful shutdown is complete, disk corruption can
occur. You can move the power switch to OFF before the shutdown. The system ignores it.
Caution
After removing power from the chassis by unplugging the power cord, wait at least 10 seconds before
turning power back ON. You want to keep the system power off, including the standby power, for 10
seconds.
Note
8-Port 1/10/25-Gb Network Module
The Secure Firewall chassis has two network module slots named NM-2 and NM-3 (left to right on the front
panel). Network modules are optional, removable I/O modules that provide either additional ports or different
interface types. The network module plugs into the chassis on the front panel. See Front Panel, on page 8
for the location of the network module slots on the chassis.
FPR-X-NM-8X10G supports 1 Gb and 10 Gb full-duplex Ethernet traffic per port and is supported on all
Secure Firewall 4200s. FPR-X-NM-8X25G supports 1 Gb, 10 Gb, or 25 Gb full-duplex Ethernet traffic per
port and is supported on all Secure Firewall 4200s.
The top ports are numbered from left to right—Ethernet 2/1 or 3/1, Ethernet 2/3 or 3/3, Ethernet 2/5 or 3/5,
and Ethernet 2/7 or 3/7. The bottom ports are numbered from left to right—Ethernet 2/2 or 3/2, Ethernet 2/4
or 3/4, Ethernet 2/6 or 3/6, and Ethernet 2/8 or 3/8 (see the figure below). Up arrows are the top ports and
down arrows are the bottom ports (see the figure below). This network module supports SFP/SFP+/SFP28
transceivers. See Supported SFP/SFP+/QSFP+ Transceivers , on page 31 for the list of Cisco-supported
transceivers.
The hardware and the system support hot swapping if you are replacing a network module with the same type
of network module. You must first disable the network port and then reenable it after replacement. If you
replace the 8-port 1/10/25-Gb network module with another supported network module, you must reboot the
chassis so that the new network module is recognized. See the configuration guide for your operating system
for the detailed procedures for managing network modules.
Note
The following figure shows the front panel of the 1/10-Gb and 1/10/25-Gb network module.
Cisco Secure Firewall 4200 Series Hardware Installation Guide
15
Overview
8-Port 1/10/25-Gb Network Module
