Network activity LEDs
The up arrows represent the top ports and the
down arrows represent the bottom ports.
• Off—No SFP.
• Amber—No link or a network failure.
• Green—Link is up.
• Green, flashing—Network activity.
2Captive screw1
Ejector handle4Power on LED3
Ethernet 2/2 or 3/26Ethernet 2/1 or 3/15
Ethernet 2/4 or 3/48Ethernet 2/3 or 3/37
For More Information
• See 8-Port 1/10/25-Gb Network Module, on page 15 for a description of the 1/10/25-Gb network
module.
• See 6-Port 10-Gb SR/10-Gb LR/25-Gb SR/25-Gb LR Network Module with Hardware Bypass , on
page 24 for a description of the 1/10/25-Gb network module.
• See 8-Port 1000Base-T Network Module with Hardware Bypass, on page 22 for a description of
the 1-Gb network module.
• See Install, Remove, and Replace the Network Module, on page 63 for the procedure for removing
and replacing network modules.
2-Port 100-Gb Network Module
The Secure Firewall 4200 chassis has two network module slots named NM-2 and NM-3 (left to right on the
front panel). Network modules are optional, removable I/O modules that provide either additional ports or
different interface types. The network module plugs into the chassis on the front panel. See Front Panel, on
page 8 for the location of the network module slots on the chassis.
The FPR-X-NM-2X100G supports 40/100-Gb operation. This network module has two QSFP/QSFP28 ports
and provides full-duplex Ethernet traffic per port. The maximum bandwidth supported is 200 Gb full duplex,
where each port operates at 100 Gb. The 100-Gb ports are numbered left to right, Ethernet 2/1 or 3/1 through
Ethernet 2/2 or 3/2. See Supported SFP/SFP+/QSFP+ Transceivers , on page 31 for the list of Cisco-supported
transceivers.
You can break each 100-Gb port into four 10-Gb or 25-Gb ports using the supported breakout cables. With
the two-port 100-Gb network module, you now have 8 10-Gb or 25-Gb interfaces. The added interfaces are
Ethernet 2/1/1 or 3/1/1 through Ethernet 2/1/8 or 3/1/8
Cisco Secure Firewall 4200 Series Hardware Installation Guide
18
Overview
2-Port 100-Gb Network Module
