CHAPTER 4
Installation, Maintenance, and Upgrade
• Install, Remove, and Replace the Network Module, on page 63
• Remove and Replace the SSD, on page 65
• Remove and Replace the Dual Fan Module, on page 67
• Remove and Replace the Power Supply Module, on page 68
Install, Remove, and Replace the Network Module
You can remove and replace the network modules (NM-2 and NM-3) in the Secure Firewall 4200. Although
the hardware supports removing and replacing the network module while the system is running, the software
does not currently support hot swapping. You must power down the chassis or disable the network slot to
remove and replace network modules.
See the configuration guide for your operating system for the procedure for managing network modules.
This procedure describes how to install a network module into an empty slot that has never contained a network
module, and how to remove an installed network module and replace it with another network module.
Safety Warnings
Take note of the following warnings:
Statement 1030—Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Statement 1073—No User-Serviceable Parts
There are no serviceable parts inside. To avoid risk of electric shock, do not open.
Warning
Step 1 To install a network module for the first time into an empty slot, do the following:
a) Power down the chassis by moving the power switch to the OFF position.
See Rear Panel, on page 14 for more information about the power switch. See the configuration guide for your
operating system for the procedure for installing a network module for the first time into an empty slot.
Cisco Secure Firewall 4200 Series Hardware Installation Guide
63
