Figure 14: Power Supply Module
Cord retention mechanism2Release tab1
Power cord connector4Handle3
Table 2: AC Power Supply Module Hardware Specifications
424542254215Specification
1.575 x 2.657 x 9.92 inches (40.0 x 67.5 x 252 mm)Dimensions
YesHot-swappable
1+1 maximum in parallelRedundancy
Only 200 to 240 VAC
(high line)
100 to 120 VAC (low line)
200 to 240 VAC (high line)
Input voltage
14 A at 100 VAC or 200 VACInput current (maximum)
50 to 60 Hz (nominal)Input voltage frequency
12 V +/- 5% at 100 A (low line)
12 V +/- 5% at 158 A (high line)
Output main voltage at
current
12 V at 2.5 AOutput standby voltage at
current
1200 W (low line)
1900 W (high line)
Output power
> 90% (platinum)Energy efficiency
