CHAPTER 3
Installing the Chassis
• Rack Mount the Chassis, on page 13
• Ground the Chassis, on page 20
• Connect AC Power to the Chassis, on page 21
• Connect DC Power to the Chassis, on page 23
Rack Mount the Chassis
The chassis can be mounted on a 4-post or a 2-post rack.
• Rack-Mount the Chassis in a 4-Post Rack , on page 13- Contains the procedures for mounting the chassis
in a 4-post rack.
• Rack-Mount the Chassis in a 2-Post Rack, on page 17- Contains procedures for mounting the chassis in
a 2-post rack.
When the Cisco 8200 Series Routers use port side exhaust fans and power supplies, the maximum temperature
is reduced by 5 degrees C (for example, 35 degrees C at sea level or 30 degrees C at 1500 meters).
Note
Rack-Mount the Chassis in a 4-Post Rack
This section describes how to install the router in a 4-post rack.
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Caution
The following table lists the items that are contained in the rack-mount kit.
Table 2: Rack-Mount Kit
Part DescriptionQuantity
Rack-mount brackets2
Hardware Installation Guide for Cisco 8200 Series Routers
13

Cisco 8200 Series Specifications

General

Dimensions	Varies by model
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Power Supply	Redundant power supplies
Operating System	Cisco IOS XR
Security Features	ACLs
Virtualization	Supports virtualization features
Product Type	Router
Interfaces	10GE, 40GE, 100GE, 400GE
Ports	Varies by model
Routing Protocols	BGP, OSPF, IS-IS
Weight	Varies by model
Humidity	5% to 95% noncondensing
