3-28
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16215-12
Chapter 3 Connecting the Router
Connecting the AC Adapter
Figure 3-24 Connecting PoE for the Cisco 880 and the Cisco 890 Series Routers
The Cisco 880 series ISRs with embedded WLAN antennas require a single external power supply: a
30-W power supply for non-POE-enabled routers or a 60-W power supply for POE-enabled routers. For
the back panels of some of these routers, see Figure 1-19 and Figure 1-21.
For more information on configuring PoE, refer to the Cisco 860 Series, Cisco 880 Series, and Cisco 890
Series Integrated Services Routers Software Configuration Guide.
Connecting the AC Adapter
Warning The device is designed to work with TN power systems. Statement 19
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that
the protective device is rated not greater than:
120 VAC, 20 A U.S. (240 VAC, 16 to 20 A international). Statement 1005
Warning This unit might have more than one power supply connection. All connections must be removed to
de-energize the unit. Statement 1028
1 48-VDC PoE input jack 4 AC plug
2 Power cord 5 12-VDC input power-jack plug
3 Power adapter—48 VDC 6 Power adapter—12 VDC
231995
5
22
6
4
4
3
1

Cisco 880 Series Specifications

General

Operating System	Cisco IOS
Device Type	Router
LAN Ports	4
LAN Interface	Fast Ethernet
VPN Support	Yes
Security	Yes
Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Network / Transport Protocol	TCP/IP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, Telnet, SSH
Features	Quality of Service (QoS), VLAN support, firewall
Encryption Algorithm	DES, Triple DES, AES
Authentication Method	RADIUS, TACACS+
Compliant Standards	IEEE 802.1Q
RAM	256 MB
Memory	256 MB DRAM
