Chapter 1 Product Overview
Cisco C881, C886, and C887 Series ISRs
Cisco C881 Router
Figure 1-22 shows the front panel of the Cisco C881 Router.
Figure 1-22 Front Panel of the Cisco C881 Router
For detailed description about the LEDs on the Cisco C880 Series Routers, see the “LEDs” section on
page 1-47.
CiscoCisco
800
Series
OKOK
POEOE
PPPPPP
FEFE4
WAN
0 1
VPN
0 1 2
3
FE
FE LAN
361124
1
1 LEDs
