1-52
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16215-12
Chapter 1 Product Overview
Hardware Features
Table 1-12 describes the LEDs for the Cisco 892FSP.
Table 1-12LED description for Cisco 892FSP ISR, 896VA, 897VA, and 898EA Routers
Shared LEDs on the Cisco 881-V and Cisco 887VA-V Voice and Data Routers
On the Cisco 881-V, Cisco 887VA-V, and Cisco 887VA-V-W routers, the BRI1, BRI2 and the FXS ports
share LED indicators. The following ports share an LED indicator:
• BRI 1B1 channel and FXS 3
• BRI 1B2 channel and FSX 4
• BRI 2B1 channel and FXS 5
• BRI 2 B2 channel and FXS 6
LED Color Activity Description
PWR_OK Green Power Status Off—No power.
Steady on—Normal operation.
Blink—Boot up phase or in ROM Monitor mode.
GE0 Green/Amber Link Status Green On—Ethernet port is connected.
Amber On—Fault with PoE. There is a fault with
the inline power supply.
Green/Amber Blinking—Data is either being
received or being transmitted.
Green/Amber Off—Ethernet port is not
connected.
GE1
GE2
GE3
GE4
GE5 Green Link Status On—Ethernet port is connected.
Blinking—Data is either being received or being
transmitted.
Off—Ethernet port is not connected.
GE6
GE7
GE WAN ports Green Link Status On—Port is connected.
Blinking—Data is either being received or being
transmitted.
Off—No link.
SFP WAN
ports
Green Link Status On—Port is connected.
Blinking—Data is either being received or being
transmitted.
Off—No link.
VPN_OK Green — Off—No tunnel.
Steady on—At least one tunnel is up.
PPP_OK Green — Off—No PPP session.
Steady on—At least one PPP established.
