Cisco 880 Series User Manual

3-39
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
OL-16215-12
Chapter 3 Connecting the Router
Connecting a Small Form-Factor Pluggable Module
Figure 3-34 Figure 5-42 Disconnecting SFP Latch Mechanisms
Tip Use a pen, screwdriver, or other small straight tool to gently release a bale-clasp handle if you cannot
reach it with your fingers.
Step 3 Grasp the SFP on both sides and remove it from the router.
Online Insertion and Removal
Online insertion and removal (OIR) of the SFP module is supported on the Cisco 892F ISRs.
Note If an SFP module is inserted with auto-failover or SFP media-type already configured, the port is forced
to the speed and duplex capability of the SFP. For a 100 base SFP, the speed is set to 100 and duplex can
be configured to either half or full. For a 1000 base SFP, the speed is set to 1000 and duplex is set to full.
1 Sliding latch 3 Bale-clasp latch
2 Swing and slide latch 4 Plastic collar latch
117722
1 2 3 4
A
B

Cisco 880 Series Specifications

General

Operating System	Cisco IOS
Device Type	Router
LAN Ports	4
LAN Interface	Fast Ethernet
VPN Support	Yes
Security	Yes
Firewall	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Network / Transport Protocol	TCP/IP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS, Telnet, SSH
Features	Quality of Service (QoS), VLAN support, firewall
Encryption Algorithm	DES, Triple DES, AES
Authentication Method	RADIUS, TACACS+
Compliant Standards	IEEE 802.1Q
RAM	256 MB
Memory	256 MB DRAM
