Cisco 8865 Series Administration Guide

Figure 17: Phone to Wall Bracket Attachment
Step 5 Press the phone firmly into the wall bracket and slide the phone down. The tabs in the bracket click into
position.
Step 6 Proceed to Adjust the Handset Rest, on page 115.
Remove the Phone from the Non-Lockable Wall Mount
The phone mounting plate contains two tabs to lock the plate into the wall bracket. The following figure shows
the location and shape of the tabs.
Cisco IP Phone 7800 Series Multiplatform Phones Administration Guide
105
Hardware and Accessory Installation
Remove the Phone from the Non-Lockable Wall Mount

Cisco 8865 Series Specifications

General

Resolution	800 x 480 pixels
Speakerphone	Full-duplex speakerphone
Codec Support	G.711, G.722, G.729, iLBC, Opus
Audio	Wideband audio
Ethernet	10/100/1000 Mbps
USB Ports	2 USB ports
Video	720p HD video
Power	IEEE 802.3af/at Power over Ethernet (PoE)
Protocols	SIP
Headset Connector	RJ9 headset port
Security	802.1X, TLS, SRTP
Weight	1.6 kg
