Cisco 8865 Series Administration Guide

Figure 29: Adjust the Handset Rest
Procedure
Step 1 Remove the handset from the cradle and pull the plastic tab from the handset rest.
Step 2 Rotate the tab 180 degrees.
Step 3 Hold the tab between two fingers, with the corner notches facing you.
Step 4 Line up the tab with the slot in the cradle and press the tab evenly into the slot. An extension protrudes from
the top of the rotated tab.
Step 5 Return the handset to the handset rest.
Cisco IP Phone 7800 Series Multiplatform Phones Administration Guide
116
Hardware and Accessory Installation
Adjust the Handset Rest

Cisco 8865 Series Specifications

General

Resolution	800 x 480 pixels
Speakerphone	Full-duplex speakerphone
Codec Support	G.711, G.722, G.729, iLBC, Opus
Audio	Wideband audio
Ethernet	10/100/1000 Mbps
USB Ports	2 USB ports
Video	720p HD video
Power	IEEE 802.3af/at Power over Ethernet (PoE)
Protocols	SIP
Headset Connector	RJ9 headset port
Security	802.1X, TLS, SRTP
Weight	1.6 kg
