Cisco ASA 5550 Series

Chapter 3 Installing the Cisco ASA 5550 Security Appliance
Installing the Chassis
3-4
Cisco ASA 5550 Getting Started Guide
78-17644-01
Rack-Mounting the Chassis
To rack-mount the chassis, perform the following steps:
Step 1 Attach the rack-mount brackets to the chassis using the supplied screws. Attach
the brackets to the holes as shown in Figure 3-2. After the brackets are secured to
the chassis, you can rack-mount it.
Figure 3-2 Installing the Right and Left Brackets
Step 2
Attach the chassis to the rack using the supplied screws, as shown in Figure 3-3.
153216
LNK
1
2
3
