Balancing Traffic to Maximize Throughput
2-4
Cisco ASA 5550 Getting Started Guide
78-17644-01
Figure 2-4 illustrates several configurations that do not enable the adaptive
security appliance to deliver maximum throughput because network traffic flows
through only one bus on the device.
Figure 2-4 Configurations Not Enabling Maximum Throughput
