Cisco ASR 1004 Overview And Installation

SPA subslot 17ASR 1000 Series SIP slot
0
3
SPA subslot 38ASR 1000 Series SIP slot
1
4
Installation Methods
Although rack-mounting is the preferred method of installation for the Cisco ASR 1004 Router, you can
mount the chassis:
•
On an equipment shelf or tabletop
•
In a19-inch wide (standard), 4-post equipment rack or two-post, using the rack-mount brackets in the
accessory kit
The Cisco ASR 1004 Router usually ships fully loaded. However, you can remove components from the
chassis to make the chassis lighter for your rack installation.
Note
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
•
The Cisco ASR 1004 Router requires a minimum of 4 rack units (7 inches or 17.8 cm) of vertical rack
space. Measure the proposed rack location before mounting the chassis in the rack.
•
Before using a particular rack, check for obstructions (such as a power strip) that could impair rack-mount
installation. If a power strip does impair a rack-mount installation, remove the power strip before installing
the chassis, and then replace it after the chassis is installed.
•
Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it back
near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving cards,
connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches (48.3 cm) of
clearance to remove field-replaceable units.
•
Maintain a minimum clearance of 3 inches (7.62 cm) on the front, top, and sides of the chassis for the
cooling air inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested rack
or directly next to another equipment rack; otherwise, the heated exhaust air from other equipment can
enter the inlet air vents and cause an overtemperature condition inside the router.
To prevent chassis overheating, never install a Cisco ASR 1004 Router in an enclosed room that is not
properly ventilated or air conditioned.
Caution
Cisco ASR 1000 Series Router Hardware Installation Guide
6
Cisco ASR 1004 Router Overview and Installation
Installation Methods

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
