4.6.2 IPsec Transforms and Lifetimes
Regardless of the IKE version selected, the TOE must be configured with the proper transform
for IPsec ESP encryption and integrity as well as IPsec lifetimes.
TOE-common-criteria(config)# crypto ipsec transform-set example esp-aes 128 esp-
sha-hmac
Note that this configures IPsec ESP to use HMAC-SHA-1 and AES-CBC-128. To
change this to the other allowed algorithms the following options can replace
‘esp-aes 128’ in the command above:
Encryption Algorithm
Command
AES-CBC-256
esp-aes 256
AES-GCM-128
esp-gcm 128
AES-GCM-256
esp-gcm 256
Note: The size of the key selected here must be less than or equal to the key size
selected for the IKE encryption setting in 4.6.1.1 and 4.6.1.2 above. If AES-
CBC-128 was selected there for use with IKE encryption, then only AES-CBC-
128 or AES-GCM-128 may be selected here.
TOE-common-criteria(config-crypto)#mode tunnel
This configures tunnel mode for IPsec. Tunnel is the default, but by explicitly
specifying tunnel mode, the router will request tunnel mode and will accept only
tunnel mode.
TOE-common-criteria(config-crypto)#mode transport
This configures transport mode for IPsec.
TOE-common-criteria (config)#crypto ipsec security-association lifetime seconds
28800
The default time value for Phase 2 SAs is 1 hour. There is no configuration
required for this setting since the default is acceptable, however to change the
setting to 8 hours as claimed in the Security Target the crypto ipsec security-
association lifetime command can be used as specified above.
TOE-common-criteria (config)#crypto ipsec security-association lifetime kilobytes
100000
This configures a lifetime of 100 MB of traffic for Phase 2 SAs. The default
amount for this setting is 2560KB, which is the minimum configurable value for
this command. The maximum configurable value for this command is 4GB.
Additional information regarding configuration of IPsec can be found in [10]. The IPSEC
commands are dispersed within the Security Command References.
• This functionality is available to the Privileged Administrator. Configuration of VPN
settings is restricted to the privileged administrator.
