Cisco ASR 9000 Series Service Configuration Guide

Configuring Access Node Control Protocol on Cisco ASR 9000 Series Routers
How to Configure ANCP on Cisco ASR 9000 Series Routers
QC-103
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
SUMMARY STEPS
1. configure
2. ancp rate-adjustment dsl-type access-loop-type percent-factor factor
3. end
or
commit
4. show ancp summary detail
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)#
Enters global configuration mode.
Step 2
ancp rate-adjustment dsl-type
access-loop-type percent-factor factor
Example:
RP/0/RSP0/CPU0:router(config)# ancp
rate-adjustment adsl2 ethernet
percent-factor 90
Sets the parameters for the ANCP shaper percent
factor. dsl-type and access-loop-type are compared
to appropriate values in optional type-length
values (TLVs) in the ANCP Port Up message and
the ANCP rate is adjusted by a configured factor in
case of a match.
• dsl-type—(Required) Sets DSL type code:
adsl1
adsl2
adsl2+
vdsl1
vdsl2
sdsl
• access-loop-type—(Required) Sets
access-loop-type to ATM or Ethernet.
• percent-factor factor—(Required) A percent
value to be applied to the ANCP reported rate
update prior to configuring it as a shaping rate.
