Cisco ASR 9000 Series Service Configuration Guide

QC-155
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Configuring Modular QoS on Link Bundles on
Cisco ASR 9000 Series Routers
A link bundle is a group of one or more ports that are aggregated together and treated as a single link.
This module describes QoS on link bundles.
Line Card, SIP, and SPA Support
Feature History for Configuring QoS on Link Bundles on Cisco ASR 9000 Series Routers
Contents
• Link Bundling Overview, page 155
• Load Balancing, page 156
• QoS and Link Bundling, page 157
• Additional References, page 158
Link Bundling Overview
The Link Bundling feature allows you to group multiple point-to-point links together into one logical
link and provide higher bidirectional bandwidth, redundancy, and load balancing between two routers.
A virtual interface is assigned to the bundled link. The component links can be dynamically added and
deleted from the virtual interface.
The virtual interface is treated as a single interface on which one can configure an IP address and other
software features used by the link bundle. Packets sent to the link bundle are forwarded to one of the
links in the bundle.
Feature ASR 9000 Ethernet Line Cards SIP 700 for the ASR 9000
QoS on Link Bundles yes no
Release Modification
Release 3.9.0 The QoS on Link Bundles feature was introduced on ASR 9000 Ethernet
Line Cards.
