Configuring Access Node Control Protocol on Cisco ASR 9000 Series Routers
How to Configure ANCP on Cisco ASR 9000 Series Routers
QC-100
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Mapping AN Ports to VLAN Subinterfaces
Port mapping associates DSLAM access ports or customer premises equipment (CPE) clients of a
DSLAM with VLAN subinterfaces. The VLANs can be IEEE 802.1Q or QinQ hierarchical VLANs. To
map AN ports to VLAN subinterfaces, use the ancp an-port command in global configuration mode.
SUMMARY STEPS
1. configure
2. ancp an-port circuit-id Access-Loop-Circuit-Id [interface type interface-path-id | interface
Bundle-Ether bundle-id]
3. end
or
commit
4. show ancp an-port {circuit-id Access-Loop-Circuit-Id | interface type interface-path-id |
interface Bundle-Ether bundle-id | mapping} [statistics | detail]
5. show ancp an-port [configured | dynamic-only] [statistics]
6. show ancp an-port summary [statistics] [detail]
7. clear ancp an-port {all | circuit-id Access-Loop-Circuit-Id | interface type interface-path-id |
interface Bundle-Ether bundle-id | neighbor {description string | sender-name {H.H.H |
A.B.C.D}} [statistics]
8. show ancp an-port {description description-string | sender-name {H.H.H | A.B.C.D}}
9. show ancp an-port state [up | down | none] [statistics]
Step 9
show ancp neighbor [all] [statistics]
Example:
RP/0/RSP0/CPU0:router# show ancp neighbor
statistics
(Optional) Displays ANCP neighbor information.
Step 10
show ancp neighbor state [none | synsent |
synrcvd | estab} [statistics]
Example:
RP/0/RSP0/CPU0:router# show ancp neighbor
none
(Optional) Displays adjacency protocol state
information.
Command or Action Purpose
