Cisco ASR 9000 Series Service Configuration Guide

Configuring Hierarchical Modular QoS on Cisco ASR 9000 Series Routers
How to Configure Hierarchical QoS
QC-140
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
4. end
or
commit
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
pos 0/2/0/0
Specifies the interface to attach the hierarchical
policy.
Step 3
service-policy {input | output}
policy-map-name
Example:
RP/0/RSP0/CPU0:router(config-if)#
service-policy input All_Traffic
Attaches the policy map you specify.
• input—Apply the QoS policy to inbound
packets.
• output—Apply the QoS policy to outbound
packets.
• policy-map-name—Name of a previously
configured top-level policy map
Step 4
end
or
commit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# end
or
RP/0/RSP0/CPU0:router(config-pmap-c)#
commit
Saves configuration changes.
• When you issue the end command, the system
prompts you to commit changes:
Uncommitted changes found, commit them
before exiting (yes/no/cancel)?
[cancel]:
– Entering yes saves configuration changes
to the running configuration file, exits the
configuration session, and returns the
router to EXEC mode.
– Entering no exits the configuration
session and returns the router to EXEC
mode without committing the
configuration changes.
– Entering cancel leaves the router in the
current configuration session without
exiting or committing the configuration
changes.
• Use the commit command to save the
configuration changes to the running
configuration file and remain within the
configuration session.
