Configuring Modular QoS Service Packet Classification and Marking on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Packet Classification and Marking on Cisco ASR 9000 Series Routers
QC-21
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Step 7
match source-address mac source-mac-address
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match
source-address mac 00.00.00
(Optional) Configures the match criteria for a class map
based on the specified source MAC address.
Step 8
match [not] discard-class discard-class-value
[
discard-class-value1 ... discard-class-value6 ]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match
discard-class 5
(Optional) Specifies a discard-class-value in a class map to
match packets.
• discard-class-value argument is specified as an integer
from 0 to 7.
The match discard-class command is supported only for an
egress policy.
Step 9
match [not] dscp [ipv4 | ipv6] dscp-value
[
dscp-value ... dscp-value ]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match dscp
ipv4 15
(Optional) Identifies a specific DSCP value as a match
criterion.
• Value range is from 0 to 63.
• Reserved keywords can be specified instead of numeric
values.
• Up to eight values or ranges con be used per match
statement.
Step 10
match [not] mpls experimental topmost exp-value
[
exp-value1 ... exp-value7 ]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match mpls
experimental topmost 3
(Optional) Configure a class map so that the three-bit
experimental field in the topmost Multiprotocol Label
Switching (MPLS) labels are examined for experimental
(EXP) field values.
The value range is from 0 to 7.
Step 11
match [not] precedence [ipv4 | ipv6]
precedence-value [ precedence-value1 ...
precedence-value6
]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match
precedence ipv4 5
(Optional) Identifies IP precedence values as match criteria.
• Value range is from 0 to 7.
• Reserved keywords can be specified instead of numeric
values.
Step 12
match [not] protocol protocol-value
[ protocol-value1 ... protocol-value7 ]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match
protocol igmp
(Optional) Configures the match criteria for a class map on
the basis of the specified protocol.
Step 13
match [not] qos-group [ qos-group-value1 ...
qos-group-value8 ]
Example:
RP/0/RSP0/CPU0:router(config-cmap)# match
qos-group 1 2 3 4 5 6 7 8
(Optional) Specifies service (QoS) group values in a class
map to match packets.
• qos-group-value identifier argument is specified as the
exact value or range of values from 0 to 63.
• Up to eight values (separated by spaces) can be entered
in one match statement.
• match qos-group command is supported only for an
egress policy.
Command or Action Purpose
