Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Service Packet Classification and Marking on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Packet Classification and Marking on Cisco ASR 9000 Series Routers
QC-30
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
SUMMARY STEPS
1. configure
2. policy-map policy-name
3. class class-name
4. set precedence number
5. set dscp dscp-value
6. set qos-group qos-group-value
7. set cos [inner] cos-value
8. set mpls experimental {imposition | topmost} exp-value
9. set discard-class discard-class-value
10. exit
11. exit
12. interface type interface-path-id
13. service-policy {input | output} policy-map
14. end
or
commit
15. show policy-map interface type instance [input | output]
Note Although this task illustrates all of the possible set commands, only two set commands can be configured
per class.
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
policy-map policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map
policy1
Enters policy map configuration mode.
• Creates or modifies a policy map that can be attached to
one or more interfaces to specify a service policy.
Step 3
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class1
Enters policy class map configuration mode.
• Specifies the name of the class whose policy you want
to create or change.
