Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Service Packet Classification and Marking on Cisco ASR 9000 Series Routers
Configuration Examples for Configuring Modular QoS Packet Classification and Marking on Cisco ASR 9000 Series
QC-37
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
QoS Group Marking Configuration: Example
In the following example, a service policy called policy1 is created. This service policy is associated to
a class map called class1 through the use of the class command, and then the service policy is attached
in the input direction on a GigabitEthernet interface 0/1/0/9. The qos-group value is set to 1.
class-map match-any class1
match protocol ipv4
match access-group ipv4 101
policy-map policy1
class class1
set qos-group 1
!
interface gigabitethernet 0/1/0/9
service-policy input policy1
Note The set qos-group command is supported only on an ingress policy.
CoS Marking Configuration: Example
In the following example, a service policy called policy1 is created. This service policy is associated to
a class map called class1 through the use of the class command, and then the service policy is attached
in the output direction on a 10-Gigabit Ethernet interface, TenGigE0/1/0/0. The IEEE 802.1p (CoS) bits
in the Layer
2 header are set to 1.
class-map match-any class1
match protocol ipv4
match access-group ipv4 101
policy-map policy1
class class1
set cos 1
!
interface TenGigE0/1/0/0
service-policy output policy1
MPLS Experimental Bit Imposition Marking Configuration: Example
In the following example, a service policy called policy1 is created. This service policy is associated to
a class map called class1 through the use of the class command, and then the service policy is attached
in the input direction on a 10-Gigabit Ethernet interface, TenGigE0/1/0/0. The MPLS EXP bits of all
imposed labels are set to 1.
class-map match-any class1
match protocol ipv4
match access-group ipv4 101
policy-map policy1
class class1
set mpls exp imposition 1
!
interface TenGigE0/1/0/0
service-policy input policy1
