Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Management on Cisco ASR 9000 Series Routers
How to Configure QoS Congestion Management on Cisco ASR 9000 Series Routers
QC-66
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
8. exit
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
policy-map policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map
policy1
Enters policy map configuration mode.
• Creates or modifies a policy map that can be attached to
one or more interfaces to specify a service policy.
Step 3
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class1
Enters policy map class configuration mode.
• Specifies the name of the class whose policy you want
to create or change.
Step 4
service-policy policy-map-name
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)#
service-policy child
Attaches a policy map to an input or output interface to be
used as the service policy for that interface.
Step 5
police rate percent percentage
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# police
rate percent 50
Configures traffic policing and enters policy map police
configuration mode.
Step 6
conform-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
conform-action transmit
Configures the action to take on packets that conform to the
rate limit. The allowed action is:
transmit—Transmits the packets.
Step 7
exceed-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
exceed-action drop
Configures the action to take on packets that exceed the rate
limit. The allowed action is:
drop—Drops the packet.
