Catalyst 2960-S Switch Hardware Installation Guide
OL-19732-04
Chapter 1 Switch Installation
10/100 and 10/100/1000 Port Connections
10/100 and 10/100/1000 Port Connections
The switch 10/100 and 10/100/1000 port configuration changes to operate at the speed of the attached
device. If the attached ports do not support autonegotiation, you can manually set the speed and duplex
parameters. Connecting devices that do not autonegotiate or that have the speed and duplex parameters
manually set can reduce performance or result in no linkage.
To maximize performance, choose one of these methods for configuring the Ethernet ports:
• Let the ports autonegotiate both speed and duplex.
• Set the interface speed and duplex parameters on both ends of the connection.
Use the guidelines in Table 1-1 to select the correct cable for connecting the switch 10/100 and
10/100/1000 ports to other devices. See the “Connector and Cable Specifications” section on page 1-1
for cable-pinout descriptions.
Where to Go Next
To change the switch settings, you can use the switch default configuration or use any of the management
options described in the “Management Options” section.
Switch to computer or server No Yes
Switch to router No Yes
Switch to IP phone No Yes
1. 100BASE-TX and 1000BASE-T traffic requires twisted four-pair, Category 5, Category 5e, or
Category 6 cable. 10BASE-T traffic can use Category 3 or Category 4 cable.
Table 1-1 Recommended Ethernet Cables (When Auto-MDIX is Disabled) (continued)
Device Crossover Cable
1
Straight-Through Cable
1
