Cisco Catalyst 9200 Series Installation Guide

Single Access Switch
(Redundant Port Channel
Uplink)
Single Access Switch
(Single Port Channel
Uplink)
Single Access Switch
(Single Uplink)
Setting
Version 2Version 2Version 2SSH
EnabledEnabledEnabledSCP
EnabledEnabledEnabledVTY Access to Switch
EnabledEnabledEnabledService Timestamp
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
VLAN
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Management Interface
IPv6 host policy createdIPv6 host policy createdIPv6 host policy createdIPv6 Host Policy
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
QoS Policy for Downlink
Ports
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for Uplink
Ports
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected uplink interfaces
configured as trunk ports,
set to allow all VLANs
Uplink Interfaces
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink Interfaces
Port-channel to
distribution created
Port-channel to
distribution created
Not configuredPort-channel
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
55
Configuring the Switch
Configuring Your Device Based on a Site Profile

Cisco Catalyst 9200 Series Specifications

General

Category	Switch
Stacking Bandwidth	160 Gbps
Layer	Layer 2 and Layer 3
Operating System	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Series	Cisco Catalyst 9200 Series
Ports	24 or 48 Ethernet ports
Switching Capacity	Up to 176 Gbps
PoE	PoE, PoE+, and UPOE
Stacking	StackWise-160
Memory	4 GB DRAM, 4 GB Flash
Network Management	Cisco DNA Center, WebUI, CLI
Security Features	802.1X, TrustSec, MACsec
Warranty	Limited Lifetime Warranty
Dimensions	1.73 x 17.5 x 11.3 in. (4.4 x 44.5 x 28.8 cm)
